ASCO S261 Pilot Operated Gas Shutoff Valve

  • $140.00


BULK ORDERS AND LESS COMMON PRODUCTS MAY REQUIRE ADDITIONAL TIME FOR SHIPMENT. CONTACT US VIA PHONE OR EMAIL TO REQUEST MORE INFORMATION ON AVAILABILITY.

Please call or email for information regarding Part numbers and prices not already listed

The ASCO Series S261 is a line of solenoid valves designed for on-off control of fuel gas in commercial and industrial gas burners. The pilot-operated valves have die-cast aluminum bodies, are designed for 2-way, normally closed operation, and have high-pressure capabilities.

Available Models:
  • S261SH02N3DG5: Gas Shutoff Valve 1/2" NPT, 120V, N/C, 3/4" ORF, 5.4CV, Max.30PSI, CSA 6.5
  • S261SH02N3EG5: Gas Shutoff Valve 3/4" NPT, 120V, N/C, 3/4" ORF, 8CV, Max.30PSI, CSA 6.5
  • S261SH02N3FJ5: Gas Shutoff Valve 1" NPT, 120V, N/C, 1-5/8"" ORF, 18.1CV, Max.25PSI, CSA 6.5
  • S261SH02N3GJ7: Gas Shutoff Valve 1-1/4" NPT, 120V, N/C, 1-5/8"" ORF, 32CV, Max.25PSI, CSA 6.5
  • S261SH02N3HJ7: Gas Shutoff Valve 1-1/2" NPT, 120V, N/C, 1-5/8"" ORF, 35CV, Max.25PSI, CSA 6.5
  • S261SH02N3JK4: Gas Shutoff Valve 2" NPT, 120V, N/C, 3" ORF, 83CV, Max.25PSI, CSA 6.5
  • S261SH02N3KK4: Gas Shutoff Valve 2-1/2" NPT, 120V, N/C, 3" ORF, 117CV, Max.25PSI, CSA 6.5

Features:

  • Provided with 1/8-inch NPT upstream and downstream pipe taps with plugs for routine testing
  • Zero differential piloted diaphragm
  • Suitable for ambient temperatures up to 175°F
  • Opening and closing times are less than 1 second
  • Available in 3/8-inch to 3-inch sizes for a wide variety of applications
  • All models are UL/CSA-rated; FM rating on 3/8-inch to 3/4-inch sizes

Specifications

  • Valve Actuation: Solenoid
  • Body Material: Aluminum
  • Media: Natural Gas
  • Pipe / Port Size: 1/2 "; 3/8 "; 3/4 "; 1 "; 1 1/4 "; 1 1/2 "; 2 "; 2 1/2 "; 3 "
  • Port Type: NPTF
  • Function: 2 way - 2/2 Normally Open
  • Voltage: 24 AC, 120 AC, 230 AC
  • Max Differential / Max Operating Pressure: Vacuum to 150 PSIG
  • Operating Environment: Indoor
  • Standards / Regulations: CSA, UL, FM
