Dungs SV../614 Safety Shut Off Valve with Proof of Closure

Dungs SV../614 Safety Shut Off Valve with Proof of Closure

CSA 6.5 Approved

THIS PRODUCT REQUIRES ADDITIONAL TIME FOR SHIPMENT. CONTACT US VIA PHONE OR EMAIL TO REQUEST MORE INFORMATION ON AVAILABILITY.

Please call or email for information regarding Part numbers and prices not already listed


The DUNGS SV and the SV-DLE are electrically operated, normally closed, automatic shutoff valves for gas burning equipment. The SV & SV-DLE /614 Incorporate overtravel and a proof of closure switch.

The SV and SV-DLE are recommended for industrial and commercial heating applications that require one or two automatic shutoff valves in series with proof of closure. The SV and SV-DLE safety shutoff valves are suitable for natural gas, propane, butane, air and other inert gases.

Valves include Flange on Outlet, for an optional Flange on Inlet, see Flange Kits or add Flange Kit  to valve in options.

Use with:

Specifications:

  • Pipe thread (NPT): 1/2" 3/4" 1" 1 1/4" 1 1/2" 2"
  • Max. operating pressure: 10 PSI (700 mbar) CSA
  • Max. close off pressure: 15 PSI (1000 mbar)
  • Electrical ratings (+10% / -15%): 120 Vac 50 - 60 Hz
  • Enclosure rating:
    • NEMA Type 4 - Mounted upright only. Indoor
    • NEMA 12, Outdoor
  • Electrical connection: DIN-connector with 1/2” NPT conduit adapter
  • Operating time: 100 % duty cycle
  • Ambient temperature rating: - 40 °F to +140 °F (-40 °C to +60 °C)


    Resources:



    Available Models:

    • SV.../614: Single-stage automatic shutoff valve, fast-opening, fast-closing. Incorporates proof of closure.
    • SV-D.../614: Single-stage automatic shutoff valve, fast opening, fast closing. Adjustable max flow. Incorporates proof of closure.
    • SV-DLE.../614: Single-stage automatic shutoff valve, slow opening, fast closing. Adjustable max flow and adjustable initial lift. Incorporates proof of closure.

    Part Numbers:

    Part Number Order Number (120 VAC) Pressure Max Operating Size
    SV-D 1005/614 277110 10 PSI 1/2" NPT
    SV-D 1007/614 277111 10 PSI 3/4" NPT
    SV 1010/614 267074  10 PSI 1" NPT
    SV 1012/614 267078 10 PSI 1-1/4" NPT
    SV 1015/614 267071  10 PSI 1-1/2" NPT
    SV 1020/614 267080  10 PSI 2" NPT
    SV-DLE 1005/614 267077  10 PSI 1/2" NPT
    SV-DLE 1007/614 267072 10 PSI 3/4" NPT
    SV-DLE 1010/614 267075  10 PSI 1" NPT
    SV-DLE 1012/614 267079  10 PSI 1-1/4" NPT
    SV-DLE 1015/614 267070  10 PSI 1-1/2" NPT
    SV-DLE 1020/614 267081  10 PSI 2" NPT


    Flange Kit Part Numbers:

    Flange kit for: (SV Valve Part Number) Size Order Number
    SV... 1005 / 1007 1/2" NPT 242650
    SV... 1005 / 1007 3/4" NPT 242651
    SV... 1010 / 1012 1/2" NPT 242653
    SV... 1010 / 1012 3/4" NPT 242654
    SV... 1010 / 1012 1" NPT 242655
    SV... 1010 / 1012 1-1/4" NPT 242656
    SV... 1010 / 1012 1-1/2" NPT 245563
    SV... 1015 / 1020 1" NPT 242657
    SV... 1015 / 1020 1-1/4" NPT 242658
    SV... 1015 / 1020 1-1/2" NPT 242659
    SV... 1015 / 1020 2" NPT 242660
